TerraCore

SKU:

¥1,000,000

¥900,000

¥900,000

Unavailable

per item

Powered by OpenKAI, this ground robotics base transforms mobility into intelligent action. Designed for stability, adaptability, and real‑time responsiveness, it serves as a foundation for autonomous systems that sense, decide, and move with purpose. Built to support the next generation of intelligent machines, on the ground and beyond.

Quantity

Add to Cart

Overview

TerraCore SpecificationsMechanical & Form Factor

• Configuration: Modular ground robotics core (track / wheel‑agnostic integration)
• Chassis: Reinforced aluminum alloy with vibration‑isolated mounting rails
• Ingress Protection: IP54–IP65 (dust‑ and splash‑resistant, configuration‑dependent)
• Operating Terrain: Indoor, outdoor, uneven surfaces, industrial environments
• Payload Interface: Standardized mechanical and electrical payload mounts

Compute & Control

• Onboard Compute: High‑performance embedded CPU with optional GPU/AI accelerator
• Real‑Time Control: Dedicated MCU for low‑latency motor and actuator control
• Operating System: OpenKAI™ Robotics OS (real‑time + autonomy stack)
• Middleware: ROS 2 compatible, DDS‑based communication layer
• Update Method: OTA and wired firmware updates

Power System

• Input Power: 24–48V DC (external battery or vehicle power bus)
• Power Distribution: Intelligent power management with per‑rail monitoring
• Aux Outputs: 5V / 12V / 24V regulated outputs for sensors and peripherals
• Protection: Over‑current, over‑voltage, thermal shutdown

Mobility Interfaces

• Motor Support: BLDC, brushed DC, stepper (CAN / UART / PWM)
• Encoder Support: Incremental and absolute encoders
• Drive Modes: Differential, skid‑steer, custom kinematic profiles
• Max Control Frequency: ≥1 kHz motor control loop

Sensors & I/O

• Standard Interfaces:
  • CAN / CAN‑FD
  • Ethernet (Gigabit)
  • USB 3.x
  • UART / I²C / SPI
  • GPIO (isolated)
• Sensor Support: LiDAR, depth cameras, IMU, GNSS, wheel odometry
• Time Sync: PTP / hardware timestamping (configuration‑dependent)

Connectivity

• Networking: Ethernet, optional Wi‑Fi / LTE / 5G module
• Remote Control: Secure telemetry and command channel
• Security: Hardware root of trust, encrypted communications

Environmental

• Operating Temperature: −10°C to +50°C (extended range optional)
• Vibration Resistance: Industrial‑grade shock and vibration tolerance
• Cooling: Passive + controlled active cooling (load‑dependent)

Software Capabilities

• Autonomy: Navigation, mapping, obstacle avoidance (module‑based)
• Integration: API access for custom behaviors and mission logic
• Simulation: Digital twin / simulator compatibility for testing

Typical Applications

• Autonomous ground robots
• Mobile robotic bases
• Inspection and logistics platforms
• Research, defense, and industrial robotics
